Multi-port 3-way Sanitary Stainless Steel Ball Valve
Vendor: Bradford
Valve Type(s):
Ball Valves
Valve Description:
Bradford™ 2-way ball valves are quarter-turn, straight through valves that use
a ball to shut off flow by sealing around matching seats to create uniform
sealing.
Ball valves are used in situations where tight shut off is necessary.
3-way ball valves are available in quarter turn or 180°.
Bradford™ ball valves provide superior ease of operation and can maintain and regulate high volume, high pressure, high temperature flow.
Bradford™ ball valves offer rugged construction providing for a long service life, and a comparably low cost.
Dixon Sanitary's offers a wide selection of ball valves for use in varies applications.
These valves are simple, rugged and above all, dependable.
Pneumatic and electric actuators are available for automated control.
All Bradford™ ball valves are assembled without silicone lubricants.
Ball valves are used in situations where tight shut off is necessary.
3-way ball valves are available in quarter turn or 180°.
Bradford™ ball valves provide superior ease of operation and can maintain and regulate high volume, high pressure, high temperature flow.
Bradford™ ball valves offer rugged construction providing for a long service life, and a comparably low cost.
Dixon Sanitary's offers a wide selection of ball valves for use in varies applications.
These valves are simple, rugged and above all, dependable.
Pneumatic and electric actuators are available for automated control.
All Bradford™ ball valves are assembled without silicone lubricants.
- Meets 3A sanitary standard 68-00 (Authorization number 1022).
- Compact design for areas with tight space restrictions
- Full port design (½" - 3") offers lower pressure drop and a less turbulent flow
- Reduced port design on 4"
- Balanced encapsulated construction minimizes cold flow of seats
- Precision stainless steel balls reduce torque and friction losses while extending seat life
- Ball orientation is indicated with markings on the stem
- Blow-out proof stem
- Live-loaded stem packing
- ISO 5211 mounting pad
- Lockable handle can prevent accidental actuation when used
- ID polish is Ra 32 Minimum
- Rated to 1,000 PSI WOG
Valve Category:
Ball Valves
Valve Subcategory
Ball Valves
| Size | 3-way L port Part Number | Dimensions (inches) | Break torque (in-lbs.) | Weight (lbs.) | Request a Quote | ||||
| A | B | C | D | E | L port | ||||
| ½" | BV3S-LF050CC-A | 4.7 | 1.8 | 4.6 | 3.2 | 3.9 | 62 | 3.6 | Request Quote |
| ¾" | BV3S-LF075CC-A | 4.7 | 1.9 | 5.0 | 3.4 | 4.2 | 75 | 4.3 | Request Quote |
| 1" | BV3S-LF100CC-A | 5.2 | 2.3 | 6.0 | 3.8 | 5.0 | 100 | 6.8 | Request Quote |
| 1½" | BV3S-LF150CC-A | 7.2 | 2.8 | 6.9 | 4.5 | 5.8 | 262 | 12.6 | Request Quote |
| 2" | BV3S-LF200CC-A | 7.2 | 3.2 | 7.5 | 5.0 | 6.7 | 535 | 21.6 | Request Quote |
| 2½" | BV3S-LF250CC-A | 14.6 | 3.9 | 9.0 | 5.3 | 7.1 | 1250 | 33.7 | Request Quote |
| 3" | BV3S-LF300CC-A | 15.7 | 4.9 | 10.2 | 6.4 | 8.5 | 1625 | 56.4 | Request Quote |
| 4" | BV3S-LR400CC-A | 15.7 | 5.3 | 11.4 | 6.8 | 10.6 | 1875 | 85.4 | Request Quote |
| Size | 3-way T port Part Number | Dimensions (inches) | Break torque (in-lbs.) | Weight (lbs.) | Request a Quote | ||||
| A | B | C | D | E | T port | ||||
| ½" | BV3S-TF050CC-A | 4.7 | 1.8 | 4.6 | 3.2 | 3.9 | 50 | 3.6 | Request Quote |
| ¾" | BV3S-TF075CC-A | 4.7 | 1.9 | 5.0 | 3.4 | 4.2 | 60 | 4.3 | Request Quote |
| 1" | BV3S-TF100CC-A | 5.2 | 2.3 | 6.0 | 3.8 | 5.0 | 80 | 6.8 | Request Quote |
| 1½" | BV3S-TF150CC-A | 7.2 | 2.8 | 6.9 | 4.5 | 5.8 | 210 | 12.6 | Request Quote |
| 2" | BV3S-TF200CC-A | 7.2 | 3.2 | 7.5 | 5.0 | 6.7 | 425 | 21.6 | Request Quote |
| 2½" | BV3S-TF250CC-A | 14.6 | 3.9 | 9.0 | 5.3 | 7.1 | 1000 | 33.7 | Request Quote |
| 3" | BV3S-TF300CC-A | 15.7 | 4.9 | 10.2 | 6.4 | 8.5 | 1300 | 56.4 | Request Quote |
| 4" | BV3S-TR400CC-A | 15.7 | 5.3 | 11.4 | 6.8 | 10.6 | 1500 | 85.4 | Request Quote |
All dimensions are in inches.
Dimensions are approximate.
Engineering dimensions are available upon request.
Specifications are subject to change without notice.
Dimensions are approximate.
Engineering dimensions are available upon request.
Specifications are subject to change without notice.
 |
