Smith-Cooper International
Cooplok Adapter Elbow, Grooved x Threaded

Request a Quote

Vendor: Smith-Cooper International

Coupling Type: Oil & Petroleum Couplings

Description:

Cooplok - Adapter Elbow, Grooved x Threaded - Grooved Couplings

Coupling Category:

Oil and Petroleum Fittings

Ductile iron - full flow
Fabricated steel; not UL/FM 10” and larger (F)
16” through 24” fabricated; available upon request
Other sizes and configurations available by special order

Nominal Pipe Size IN / mm	Part Number		A IN / mm	Weight LB / kg
Nominal Pipe Size IN / mm	Painted	Galvanized	A IN / mm	Weight LB / kg
1-1/2 x 1-1/4 40 x 32	65RT3014012F	66RT3014012F	2.80 71.1	1.7 0.8
2 x 1-1/4 50 x 32	65RT3020012F	66RT3020012F	3.30 83.8	2.5 1.2
2 x 1-1/2 50 x 40	65RT3020014	66RT3020014	3.25 82.6	2.4 1.1
2-1/2 x 1-1/4 50 x 32	65RT3024012F	66RT3024012F	3.80 96.5	4.1 1.9
2-1/2 x 1-1/2 65 x 40	65RT3024014F	66RT3024014F	3.75 95.3	4.5 2.0
2-1/2 x 2 65 x 50	65RT3024020	66RT3024020	3.75 95.3	4.0 1.8
3 x 1-1/4 80 x 32	65RT3030012F	66RT3030012F	4.30 109.2	6.2 2.8
3 x 1-1/2 80 x 40	65RT3030014F	66RT3030014F	4.30 109.2	6.1 2.8
3 x 2 80 x 50	65RT3030020F	66RT3030020F	4.30 109.2	6.4 2.9
3 x 2-1/2 80 x 65	65RT3030024	66RT3030024	4.25 108.0	5.9 2.7
4 x 1-1/4 100 x 32	65RT3040012F	66RT3040012F	5.00 127.0	9.7 4.4
4 x 1-1/2 100 x 40	65RT3040014F	66RT3040014F	5.00 127.0	10.4 4.7
4 x 2 100 x 50	65RT3040020	66RT3040020	5.00 127.0	11.4 5.1
4 x 2-1/2 100 x 65	65RT3040024	66RT3040024	5.00 127.0	8.9 4.0
4 x 3 100 x 80	65RT3040030	66RT3040030	5.00 127.0	10 4.5
5 x 1 125 x 25	65RT3050010F	66RT3050010F	5.50 139.7	14.2 6.5
5 x 1-1/4 125 x 32	65RT3050012F	66RT3050012F	5.50 139.7	14.5 6.6
5 x 1-1/2 125 x 40	65RT3050014F	66RT3050014F	5.50 139.7	14.7 6.7
5 x 2 125 x 50	65RT3050020F	66RT3050020F	5.50 139.7	14.6 6.6
5 x 2-1/2 125 x 65	65RT3050024F	66RT3050024F	5.50 139.7	13.1 5.9
5 x 3 125 x 80	65RT3050030F	66RT3050030F	5.50 139.7	13.7 6.2
5 x 4 125 x 100	65RT3050040F	66RT3050040F	5.50 139.7	14.7 6.7
6 x 1 150 x 25	65RT3060010F	66RT3060010F	6.50 165.1	21.0 9.5
6 x 1-1/4 150 x 32	65RT3060012F	66RT3060012F	6.50 165.1	21.1 9.6
6 x 1-1/2 150 x 40	65RT3060014F	66RT3060014F	6.50 165.1	21.2 9.6
6 x 2 150 x 50	65RT3060020F	66RT3060020F	6.50 165.1	21.5 9.8
6 x 2-1/2 150 x 65	65RT3060024	66RT3060024	6.50 165.1	26.5 11.9
6 x 3 150 x 80	65RT3060030	66RT3060030	6.50 165.1	21.9 9.9
6 x 4 150 x 100	65RT3060040	66RT3060040	6.50 165.1	23.7 10.7
6 x 5 150 x 125	65RT3060050	66RT3060050	6.50 165.1	26.4 12.0
8 x 2 200 x 50	65RT3080020F	66RT3080020F	7.80 198.1	38.1 17.3
8 x 2-1/2 200 x 65	65RT3080024F	66RT3080024F	7.80 198.1	38.8 17.6
8 x 3 200 x 80	65RT3080030F	66RT3080030F	7.80 198.1	39.4 17.9
8 x 4 200 x 100	65RT3080040	66RT3080040	7.75 196.9	32.9 14.8
8 x 5 200 x 125	65RT3080050F	66RT3080050F	7.80 198.1	40.5 18.3
8 x 6 200 x 150	65RT3080060	66RT3080060	7.75 196.9	43.8 19.7
10 x 1-1/2 254 x 40	65RT3100014F	66RT3100014F	9.00 228.6	62.8 28.5
10 x 2 254 x 50	65RT3100020F	66RT3100020F	9.00 228.6	63.5 28.8
10 x 2-1/2 254 x 65	65RT3100024F	66RT3100024F	9.00 228.6	65.1 29.5
10 x 3 254 x 80	65RT3100030F	66RT3100030F	9.00 228.6	66.4 30.1
10 x 4 254 x 100	65RT3100040F	66RT3100040F	9.00 228.6	53.6 24.3
10 x 5 254 x 125	65RT3100050F	66RT3100050F	9.00 228.6	71.7 32.5
10 x 6 254 x 100	65RT3100060F	66RT3100060F	9.00 228.6	69.5 31.5
10 x 8 254 x 200	65RT3100080F	66RT3100080F	9.00 228.6	78.2 35.4
12 x 1 305 x 25	65RT3120010F	66RT3120010F	10.00 254.0	83.2 37.7
12 x 2 305 x 50	65RT3120020F	66RT3120020F	10.00 254.0	84.2 38.2
12 x 2-1/2 305 x 65	65RT3120024F	66RT3120024F	10.00 254.0	85.2 38.7
12 x 3 305 x 80	65RT3120030F	66RT3120030F	10.00 254.0	86.1 39.1
12 x 4 305 x 100	65RT3120040F	66RT3120040F	10.00 254.0	87.7 39.8
12 x 5 305 x 125	65RT3120050F	66RT3120050F	10.00 254.0	89.6 40.7
12 x 6 305 x 150	65RT3120060F	66RT3120060F	10.00 254.0	98.1 44.5
12 x 8 305 x 150	65RT3120080F	66RT3120080F	10.00 254.0	106.1 48.1
12 x 10 305 x 250	65RT3120100F	66RT3120100F	10.00 254.0	116.0 52.6
14 x 4 350 x 100	65RT3140040F	66RT3140040F	11.00 279.4	109.8 49.8
14 x 6 350 x 150	65RT3140060F	66RT3140060F	11.00 279.4	117.4 53.2
14 x 8 350 x 200	65RT3140080F	66RT3140080F	11.00 279.4	126.2 57.3
14 x 10 350 x 250	65RT3140100F	66RT3140100F	11.00 279.4	137.2 62.2
14 x 12 350 x 305	65RT3140120F	66RT3140120F	11.00 279.4	145.6 66.0
