Willcox Hose
Composite Rackmaster Hose

Types:
Petroleum Hose     Sub Type: Petroleum Petro Transfer Hose

Vendor: Willcox Hose

Application:

HYDROCARBON-OIL HOSES
Bottom Loading Hose
Heavy Duty Series:1061GG Polypropylene

Typical Applications: Bottom loading arms Petroleum products Ethanol, Diesel and Bio-Diesel Aviation, JP Fuels Alternative Fuels

Benefits and Features Unique fire retardant barrier layer Seamless tubes to prevent leaks and permeation 100% aromatic resistant Suitable for all formulations of gasoline, diesel and jet fuel No outer braid to fray and cut the operators hands Ozone resistant cover

Willcox Hose® Rackmaster® Bottom Loading Hose Type 1061 is specifically designed for today's gasoline and diesel formulas. A specially designed hose for bottom loading having flame resistant cloth under outer cover, galvanized, internal wire, and a heavy-gauge galvanized carbon steel external wire.  Rackmaster® Bottom Loading Hose is available as a factory assembly with fixed or floating TTMA flanges in 4" diameter standard and built to custom lengths as required. Please note: Due to the precise lengths required in this application, we require to know whether the measured length of the assembly is under pressure or not. This ensures correct calculation of the manufactured length and therefore what the under pressure length should be. All factory fitted assemblies are hydrostatically tested to 1-1/2 times MWP.

Cover:

PVC impregnated fabric cover

Temperature:

-22°F to +212°F

Couplings:

Standard TTMA flanges attached with heavy duty cadium plated steel ferrules

Lengths:

20m/ 65ft.

Colors:

Standard Color is Black

Options:

Other API colors on request

Rackmaster Dimensional Data Chart
NOMINAL ID	NOMINAL OD	MAX. WP	MIN. BEND	WEIGHT LB/FT	MAX. LENGTH	Request Quote
		PSI 70°	RADIUS IN.
IN. (MM)	IN. (MM)	(BAR)	(MM)	(KG/M)	FEET
3 (75)	3-5/8(89)	250 (17.5)	8 (200)	2.3 (3.5)	100	Request Quote
4 (100)	4-5/8(120)	250 (17.5)	13 (325)	2.3 (4.5)	100	Request Quote

Willcox Internal and External Wire Construction Identification
STYLE	INTERNAL WIRE	EXTERNAL WIRE
GG	Galvanized Steel	Galvanized Steel
PG	Black Polypropylene Coated	Galvanized Steel
PS	Black Polypropylene Coated	Stainless Steel
PP	Black Polypropylene Coated	Black Polypropylene Coated
SG	Stainless Steel	Galvanized Steel
SS	Stainless Steel	Stainless Steel

Rackmaster Special Ordering Information:
Composite hose elongates under pressure and it is imperative to provide the
factory or authorized fabricator with the specific overall length required under
a pressurized length or non-pressurized length. Rackmaster overall length
tolerance is +/- 2". Please consult JGB to assure the proper measuring
lengths.


Notes:

• Fitting pressure rating may limit working pressure of an assembly.
• Increased operating temperatures will reduce working pressure of the hose.
• Rated working pressures are 70° F or worldwide ambient temperatures.
