Novaflex
6997 Food & Beverage Suction Hose

Types:
Sanitary Food Grade     Sub Type: General Food Hose

Vendor: Novaflex

Application:

For handling beer, wine, fruit juice where taste and aroma must not be affected.
Can also be used for edible oils, such as: peanut, canola, vegetable.
Also used for draining fryers in restaurants.
Not for steam service.

Tube:

White FDA nitrile rubber

Reinforcement:

Plies of polyester tire cord with helix wire

Cover:

Smooth white high grade weather and abrasion resistant FDA nitrile rubber

Temperature:

up to 225°F.

Lengths:

100 ft.

Part No	ID	OD	Plies	WP psi	WT LBS/FT	Request Quote
6997WT-01000-20	1	1.46	2	200	0.64	Request Quote
6997WT-01250-20	1-1/4	1.71	2	200	0.76	Request Quote
6997WT-01500-20	1-1/2	2.04	2	200	1.06	Request Quote
6997WT-02000-20	2	2.63	2	150	1.68	Request Quote
6997WT-02500-20	2-1/2	3.15	2	150	2.13	Request Quote
6997WT-03000-20	3	3.65	2	150	2.5	Request Quote
6997WT-04000-20	4	4.7	2	125	3.72	Request Quote
6997WT-05000-20	5	5.75	2	100	5.5	Request Quote
