Gates
TH18 Constant Pressure Hydraulic Hose - SAE 100R18

TH18 Constant Pressure Hydraulic Hose - SAE 100R18

Types:
Hydraulic Hose


Vendor: Gates

Application:

TH18 hose meets or exceeds performance requirements of SAE 100R18 with a significantly tighter bend radius. Suitable for petroleum or synthetic–based hydraulic fluids in hydraulic systems. TH18 is ideal for industrial and agricultural applications exposed to low temperatures or cyclic and quick temperature changes. Remains highly flexible in cold weather conditions and is resistant to hydraulic fluids, high temperatures, aging and weathering.

Tube:

Polyester elastomer.

Reinforcement:

Synthetic fiber.

Cover:

Black Urethane perforated.

Temperature:

-67°F to +212°F (-55°C to +100°C) continuous service for petroleum and synthetic oils. Maximum of +158°F (+70°C) for water-based fluids.

Couplings:

MegaCrimp® Couplings (with TuffCoat® plating) (G25) Section G

Category:

Thermoplastic

Part No. Description Product No. ID OD WP Burst Pressure MBR Request a Quote
71001 4TH18XCTN 4467-0006 1/4 0.48 3000 12000 1.4 Request Quote
71002 5TH18XCTN 4467-0007 5/16 0.56 3000 12000 1.8 Request Quote
71003 6TH18XCTN 4467-0008 3/8 0.65 3000 12000 1.8 Request Quote
71004 8TH18XCTN 4467-0009 1/2 0.89 3000 12000 2.8 Request Quote
71005 10TH18XCTN 4467-0010 5/8 1.03 3000 12000 3.9 Request Quote
