Gates
C6H High Temp 1-Fiber Braid Hose SAE 100R6

Types:
Hydraulic Hose

Vendor: Gates

Application:

Hydraulic oil lines, heavy–duty transmission oil cooler lines and glycol anti–freeze solutions. Meets or exceeds requirements of SAE 100R6.

Tube:

Black, specially compounded, synthetic rubber (Nitrile).

Reinforcement:

One fiber braid.

Cover:

Black, oil and abrasion resistant, synthetic rubber (Polychloroprene).

Temperature:

For hydraulic oil lines –40°F to +275°F (–40°C to +135°C) constant and +300°F (+149°C) intermittent (up to 10% of operating time).

Couplings:

Contact JGB for proper fitting recommendation and coupling procedure.

Part No.	Description	Product No.	Standard Pack	Hose ID	Hose OD	WP	Min. Burst	MBR	Vacuum	Request a Quote
				In.	In.	psi	psi	In.
70106	3GTHXCTN	3319-3301	715	3/16	0.44	500	2000	2	28	Request Quote
70107	4GTHXCTN	3319-3305	775	1/4	0.5	400	1600	2.5	28	Request Quote
86687	5GTH X50FT	3319-0305	1	5/16	0.56	400	1600	3	28	Request Quote
70105	5GTH XBULK	3319-3309	250	5/16	0.56	400	1600	3	28	Request Quote
70108	5GTHXCTN	3319-3310	650	5/16	0.56	400	1600	3	28	Request Quote
86618	8GTH X50FT	3319-3317	1	1/2	0.78	400	1600	4	18	Request Quote
70110	8GTHXCTN	3319-3320	400	1/2	0.78	400	1600	4	18	Request Quote
70131	8GTHXREEL	3319-3323	200	1/2	0.78	400	1600	4	18	Request Quote
86695	10GTH X25FT	3319-4268	1	5/8	0.91	350	1400	5	15	Request Quote
70111	10GTHXCTN	3319-3325	250	5/8	0.91	350	1400	5	15	Request Quote
70130	12GTHXCTN	3319-3335	225	3/4	1.06	300	1200	5.5	15	Request Quote
70746	16GTHXCTN	3319-3345	165	1	1.13	250	1000	8	10	Request Quote
