Kuriyama - Kuri Tec POLYAIR HS1131, HS1134, HS1136, HS1138 Series Multi-Purpose Air Hose Assemblies
Vendor: Kuriyama
Category: Air and Multipurpose Hose
Application:
High quality flexible PVC compounds uniquely
blended to make this hose look and feel like comparable
rubber hose and stay flexible at low temperatures.
Its light weight makes it an ideal hose for air tool
applications.
- Ideal for in-plant applications requiring color coding of hose supply lines
- Transfer of air, water and mild water-soluble chemicals
- Outdoor applications requiring a low temperature hose
- General air supply line for pneumatic tools and paint spray systems.
- Low pressure spray hose for water-soluble chemicals
Features:
- U. V. and weather resistant
- Excellent cold weather flexibility
- Easily re-coiled after use
- Medium/high oil resistance, complies with ARPM’s Class B Designation.
- Non-marking pin-pricked cover
- Lightweight
- One-piece lengths
- Chemical resistance of PVC
- Silicone-free core and cover
- RoHS(16) compliant
- Phthalate Free!
Tube:
Black PVC compound
Reinforcement:
Spiral polyester yarn with additional longitudinal yarns ... reduces elongation under pressure
Cover:
PVC compound
Temperature:
-40 to 150 ºF
-40 to 65 ºC
Packaging:
Assemblies are shrink wrapped and labeled
Couplings:
1/4" ID – 1/4" X 1/4"M NPT
5/16" ID – 5/16" X 1/4"M NPT
3/8" ID – 3/8" X 1/4"M NPT
1/2" ID – 1/2" X 1/2"M NPT
5/8" ID – 5/8" X 3/4"M NPT
3/4" ID – 3/4" X 3/4"M NPT
1" ID – 1" X 1"M NPT
Category:
Kuri Tec®
Colors:
HS1131 - Yellow
HS1134 - Red
HS1136 - Blue
HS1138 - Grey
| Part Number | ID | OD | Std. Length Coils |
Approx. Wt. pere Pkg. (lbs.) |
Request a Quote |
| HS1131-04X25 | 1/4” | .500” | 25ft. | 2.2 | Request Quote |
| HS1131-04X50 | 1/4” | .500” | 50ft. | 4.4 | Request Quote |
| HS1131-04X100 | 1/4” | .500” | 100ft. | 8.8 | Request Quote |
| HS1131-06X25 | 3/8” | .625” | 25ft. | 2.9 | Request Quote |
| HS1131-06X50 | 3/8” | .625” | 50ft. | 5.8 | Request Quote |
| HS1131-06X100 | 3/8” | .625” | 100ft. | 11.6 | Request Quote |
| HS1131D-08X25 | 1/2” | .813” | 25ft. | 4.5 | Request Quote |
| HS1131D-08X50 | 1/2” | .813” | 50ft. | 9 | Request Quote |
| HS1131D-08X100 | 1/2” | .813” | 100ft. | 18 | Request Quote |
| HS1131E-12X25 | 3/4” | 1.125” | 25ft. | 7.5 | Request Quote |
| HS1131E-12X50 | 3/4” | 1.125” | 50ft. | 15 | Request Quote |
| HS1131E-12X100 | 3/4” | 1.125” | 100ft. | 30 | Request Quote |
| HS1131F-16X25 | 1” | 1.406” | 25ft. | 10.3 | Request Quote |
| HS1131F-16X50 | 1” | 1.406” | 50ft. | 20.5 | Request Quote |
| HS1131F-16X100 | 1” | 1.406” | 100ft. | 41 | Request Quote |
| HS1134-04X25 | 1/4” | .500” | 25ft. | 2.2 | Request Quote |
| HS1134-04X50 | 1/4” | .500” | 50ft. | 4.4 | Request Quote |
| HS1134-04X100 | 1/4” | .500” | 100ft. | 8.8 | Request Quote |
| HS1134-05X25 | 5/16” | .625” | 25ft. | 3.3 | Request Quote |
| HS1134-05X50 | 5/16” | .625” | 50ft. | 6.5 | Request Quote |
| HS1134-05X100 | 5/16” | .625” | 100ft. | 13 | Request Quote |
| HS1134-06X25 | 3/8” | .625” | 25ft. | 2.9 | Request Quote |
| HS1134-06X50 | 3/8” | .625” | 50ft. | 5.8 | Request Quote |
| HS1134-06X100 | 3/8” | .625” | 100ft. | 11.6 | Request Quote |
| HS1134D-08X25 | 1/2” | .813” | 25ft. | 4.5 | Request Quote |
| HS1134D-08X50 | 1/2” | .813” | 50ft. | 9 | Request Quote |
| HS1134D-08X100 | 1/2” | .813” | 100ft. | 18 | Request Quote |
| HS1134E-10X25 | 5/8” | .906” | 25ft. | 4.8 | Request Quote |
| HS1134E-10X50 | 5/8” | .906” | 50ft. | 9.5 | Request Quote |
| HS1134E-10X100 | 5/8” | .906” | 100ft. | 19 | Request Quote |
| HS1134E-12X25 | 3/4” | 1.125” | 25ft. | 7.5 | Request Quote |
| HS1134E-12X50 | 3/4” | 1.125” | 50ft. | 15 | Request Quote |
| HS1134E-12X100 | 3/4” | 1.125” | 100ft. | 30 | Request Quote |
| HS1134F-16X25 | 1” | 1.406” | 25ft. | 10.3 | Request Quote |
| HS1134F-16X50 | 1” | 1.406” | 50ft. | 20.5 | Request Quote |
| HS1134F-16X100 | 1” | 1.406” | 100ft. | 41 | Request Quote |
| HS1136-04X25 | 1/4” | .500” | 25ft. | 2.2 | Request Quote |
| HS1136-04X50 | 1/4” | .500” | 50ft. | 4.4 | Request Quote |
| HS1136-04X100 | 1/4” | .500” | 100ft. | 8.8 | Request Quote |
| HS1136-06X25 | 3/8” | .625” | 25ft. | 2.9 | Request Quote |
| HS1136-06X50 | 3/8” | .625” | 50ft. | 5.8 | Request Quote |
| HS1136-06X100 | 3/8” | .625” | 100ft. | 11.6 | Request Quote |
| HS1136D-08X25 | 1/2” | .813” | 25ft. | 4.5 | Request Quote |
| HS1136D-08X50 | 1/2” | .813” | 50ft. | 9 | Request Quote |
| HS1136D-08X100 | 1/2” | .813” | 100ft. | 18 | Request Quote |
| HS1136E-12X25 | 3/4” | 1.125” | 25ft. | 7.5 | Request Quote |
| HS1136E-12X50 | 3/4” | 1.125” | 50ft. | 15 | Request Quote |
| HS1136E-12X100 | 3/4” | 1.125” | 100ft. | 30 | Request Quote |
| HS1136F-16X25 | 1” | 1.406” | 25ft. | 10.3 | Request Quote |
| HS1136F-16X50 | 1” | 1.406” | 50ft. | 20.5 | Request Quote |
| HS1136F-16X100 | 1” | 1.406” | 100ft. | 41 | Request Quote |
| HS1138-04X25 | 1/4” | .500” | 25ft. | 2.2 | Request Quote |
| HS1138-04X50 | 1/4” | .500” | 50ft. | 4.4 | Request Quote |
| HS1138-04X100 | 1/4” | .500” | 100ft. | 8.8 | Request Quote |
| HS1138-06X25 | 3/8” | .625” | 25ft. | 2.9 | Request Quote |
| HS1138-06X50 | 3/8” | .625” | 50ft. | 5.8 | Request Quote |
| HS1138-06X100 | 3/8” | .625” | 100ft. | 11.6 | Request Quote |
| HS1138D-08X25 | 1/2” | .813” | 25ft. | 4.5 | Request Quote |
| HS1138D-08X50 | 1/2” | .813” | 50ft. | 9 | Request Quote |
| HS1138D-08X100 | 1/2” | .813” | 100ft. | 18 | Request Quote |
| HS1138E-12X25 | 3/4” | 1.125” | 25ft. | 7.5 | Request Quote |
| HS1138E-12X50 | 3/4” | 1.125” | 50ft. | 15 | Request Quote |
| HS1138E-12X100 | 3/4” | 1.125” | 100ft. | 30 | Request Quote |
NOTE: Working Pressure decreases as temperature increases. Pressure ratings can only be obtained with proper coupling procedures.
Phthalate Free(15)
 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
